Aluminium flexible air duct

Catalogue Aluminium flexible air duct

Catalogue Remak™ Flexible Air Duct

Duct is built of the aluminium laminated with the polyester & aluminum foil. It was designed especially for the needs of the ventilation and air conditioning market. It has the advantage of no need to use special tools for cutting or fixing, it does not emit toxic gases in high temperatures. it is fire resistance.

INSTRUCTIONS

1. Made of aluminum flexible material, the air ducts are specially designed for HVAC (heating, ventilation and air conditioning) systems with low and medium pressure.
2. It always be used to exhaust the stale air from the growing room and deliver fresh air by connecting it between grow tent or greenhouse and growing equipments, such as carbon filter, inline fan.
 3. The air duct can minimize the heat gain and loss resulting from the temperature differential between the airflow and the ambient air, so it can provide a better environment for plant growth by controlling the temperature and humidity of the growing room.

SPECIFICATION:

1. Aluminium foil flexible air duct is making of the aluminium foil with the polyester. It was designed especially for the needs of the ventilation and air conditioning market.

2. It has the advantage of no need to use special tools for cutting or fixing, it does not emit toxic gases in high temperatures. it is fire resistance enduring high temperature.
3. It is widely used in air conditioner.
4. Spring wire: carbon steel from 0.9~1.3mm
5. Temperature: -30C to +150C
6. Diameter: 100mm to 400mm

APPLICATION

Aluminium foil ducts are to be used in heating, ventilation, and air conditioning (HVAC) to deliver and remove air.

1. Air conditioning
2. Factory equipment
3. Vehicle construction
4. Engine construction
5. Bathroom
6. Confined space
7. Tumbler dryer/Range hood/Water heater
8. Fanner/Ventilator in industrial and household application

1. Non-insulated flexible air ducts - a five-layered air duct consists of three layers aluminum foil and two layers polyester foil which has a steel spring embedded.

Use this non-insulated and economically priced flexible connector in medium to low pressure A/C systems and in air venting and drying applications. The corrosion resistant spring steel wire helix is laminated with multiple layers of clear and metallized polyester film, fully laminated with adhesive. Oversized for quick installation.

- Diameters in stock: from f102 to f508. (diameters from f508 to f800 - on request)
-Lenght: 10m.
- Working temperature: from -300С to +1500С
- Maximum pressure: 3000Pa
- Certificates: Class B - EN 13501 - 1 - European Union

2. Insulated Flexible Air Duct - a five-layered air duct on which is laid fiberglass insulation with tickness of 25mm. 16kg/m3., coated with laminate of polyester and aluminum foil.

Our premier product, the Insulated Flexible Air Duct offers a comprehensive solution to your HVAC duct needs. Its unique woven fiberglass core is the most durable core available, and it promotes superior airflow. The rigid wire is permanently bonded to the core. Suitable for all pressure heating and cooling systems, it makes for easier and more affordable installation. The Insulated Flexible Air Duct's bi-directional reinforced metallized jacket resists tearing.

- Diameters: from f102 to f800
- Lenght: 10m.
- Working temperature: from -300С to +1500С
- Maximum pressure: 3000Pa
- Certificates: Class B - EN 13105 - 1 - European Union
